The AlarmSense encompasses all of these attributes to provide a panel that meets a variety of needs.

For the fire alarm engineer, the AlarmSense has been designed to minimise labour costs. There is ample room for wiring, changing batteries and clear indication. Activation is via key switch or access code, which means you should always be able to work on the panel and the one man walk tests will help reduce the cost of maintaining the fire alarm system.

Simplicity was one of the most important aspects when considering the end user of a fire alarm panel. The colour coded buttons and the 3 step silence gives non-technical people the confidence to correctly manage their fire alarm system.

Two or four AlarmSense fire zone circuits are privded plus two additional conventional monitored sounder circuits. Fire & Fault switched negative outputs, class change and an alert input are also included.

Haes AlarmSense panels are approved to European stadards EN54-2 & 4.

• Activate controls via keyswitch or code entry

• Soft tactile buttons for controls & programming

• Integral detector removal monitoring

• 1.25 Amp switch mode power supply Nom 27V DC

• 2 conventional monitored sounder outputs

• 2 Aux C/O relays (1 x Fire) ( 1 x Fault). Voltage free

• Class change I/P

• Alert I/P

• Fire & fault switch -ve outputs

• Test mode with or without sounders

• Disable zones, sounder O/Ps & Aux O/Ps

• Alarm load, 800mA shared between all sounder outputs
