Morley-IAS 714-001-241 DXc4 Four Loop Addressable Control Panel
INC VAT
Code: MOR/DXC4
The Morley-IAS 714-001-241 DXc4 Four Loop Addressable Control Panel features 2 sounder circuits that supports Apollo (Xplorer, XP95 and Discovery), Hochiki (ESP) & System Sensor protocol devices.
The Morley-IAS DX Connexion panel is ideally suited for use in the protection of small to medium sized buildings. All in all, a compact, high performance, feature rich, economical fire alarm control panel designed to help both the installer and the end user.
The DX Connexion is an enhancement of the Morley-IAS Dimension panel range, connecting the traditional Morley-IAS qualities of reliability, flexibility and value with advanced features and intuitive functionality.
The multi-protocol DX Connexion range of fire alarm control panels has been developed to be the most time efficient fire panel on the market to install. Simply fix the control panel to the wall, connect the field wiring, power up and in as few as five button presses you can have a compliant, working fire alarm system. The panel’s large graphical display provides a clear menu structure making the whole initial set-up process quick, clear and intuitive.
Additionally, programming the control panel couldn’t be easier. Complex configuration can be achieved by using either the panel’s mobile phone style key pad or by using the Windows PC programming tool supplied with the panel.
4 loop - 500mA per loop
Dimensions: 391.5mm H x 390mm W x 147mm D
4.5kg
3 mounting holes
Knockouts (20mm) - Top: 25x, Bottom: 2x
IP30 rated
Network up to 16 loops
True peer-to-peer and fault tolerant network for high system reliability
Supports USB upload/download
2 independent sounder circuits
2 x onboard monitored inputs
The Morley-IAS 714-001-241 DXc4 Four Loop Addressable Control Panel features 2 sounder circuits that supports Apollo (Xplorer, XP95 and Discovery), Hochiki (ESP) & System Sensor protocol devices.
The Morley-IAS DX Connexion panel is ideally suited for use in the protection of small to medium sized buildings. All in all, a compact, high performance, feature rich, economical fire alarm control panel designed to help both the installer and the end user.
The DX Connexion is an enhancement of the Morley-IAS Dimension panel range, connecting the traditional Morley-IAS qualities of reliability, flexibility and value with advanced features and intuitive functionality.
The multi-protocol DX Connexion range of fire alarm control panels has been developed to be the most time efficient fire panel on the market to install. Simply fix the control panel to the wall, connect the field wiring, power up and in as few as five button presses you can have a compliant, working fire alarm system. The panel’s large graphical display provides a clear menu structure making the whole initial set-up process quick, clear and intuitive.
Additionally, programming the control panel couldn’t be easier. Complex configuration can be achieved by using either the panel’s mobile phone style key pad or by using the Windows PC programming tool supplied with the panel.
4 loop - 500mA per loop
Dimensions: 391.5mm H x 390mm W x 147mm D
4.5kg
3 mounting holes
Knockouts (20mm) - Top: 25x, Bottom: 2x
IP30 rated
Network up to 16 loops
True peer-to-peer and fault tolerant network for high system reliability
Supports USB upload/download
2 independent sounder circuits
2 x onboard monitored inputs
